| CPU Model |
AMD Ryzen™ Embedded V1500B 4-core/8-thread 2.2 GHz processor |
| CPU Architecture |
64-bit x86 |
| Hardware Encryption Engine |
✓ (AES-NI) |
| Memory |
32 GB SODIMM DDR4 (2 x 16 GB) |
| Drive Bays |
5 x 3.5-inch + 4 x 2.5-inch |
| Compatible Drive Type |
3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA hard disk drives 2.5-inch SATA solid state drives 2.5-inch bays: 2.5-inch SATA hard disk drives 2.5-inch SATA solid state drives 2.5-inch U.2 NVMe PCIe Gen3 x4 solid state drives (2.5-inch Bay # |
| Hot Swappable Drive |
✓ |
| Power Supply Unit / Adapter |
External, 120 W, AC 100 to 240 V |
| Total Memory Slots |
2 x SODIMM DDR4 Support optional ECC memory |
| Maximum Memory Capacity |
64 GB (2 x 32 GB) |
| Form Factor (RU) |
Tower |
| RJ-45 10GbE LAN Port |
1 x 10GBASE-T (10G/5G/2.5G/1G/100M) |
| Floating Point Unit |
✓ |
| Flash Memory |
5GB (Dual boot OS protection) |
| SSD Cache Acceleration Support |
✓ |
| Wake on LAN (WOL) |
✓ |
| Jumbo Frame |
✓ |
| USB 3.2 Gen 2 (10Gbps) Port |
1 x Type-C USB 3.2 Gen 2 3 x Type-A USB 3.2 Gen 2 |
| LED Indicators |
HDD 1-5, SSD 1-4, Power/Status, LAN, USB |
| Buttons |
Power, Reset, USB Copy |
| Power Consumption: Disk Standby Mode |
41.2 |
| RJ-45 2.5GbE LAN Port |
2 (2.5G/1G/100M) |
| Power Consumption: Operating Mode, Typical |
55.41 |
| Operating System |
QTS 5.2.6 |
