| CPU Model |
AMD Ryzen™ 7 9000 Series 8C/16T 3.8 GHz, up to 5.5 GHz |
| CPU Architecture |
64-bit x86 |
| Hardware Encryption Engine |
✓ (AES-NI) |
| Memory |
32 GB UDIMM DDR5 ECC (1 x 32 GB) |
| Drive Bays |
12 x 2.5 |
| Compatible Drive Type |
2.5-inch SATA solid state drives |
| Hot Swappable Drive |
✓ (Not supported M.2 SSD) |
| USB 3.2 Gen 1 Port |
1 |
| Power Supply Unit / Adapter |
Minimum 500W, 100-240V |
| Total Memory Slots |
4 x DDR5 UDIMM |
| Maximum Memory Capacity |
192 GB (4 x 48GB) |
| M.2 Drive Slots |
Optional via PCIe adapters |
| PCIe Expansion |
3 Slot 1: Gen 4 x 4 Slot 2: Gen 4 x 8 or Gen 4 x 4* Slot 3: Gen 4 x 8 |
| Form Factor (RU) |
Tower |
| RJ-45 10GbE LAN Port |
2 x 10GBASE-T (10G/5G/2.5G/1G/100M) |
| Graphic Processors |
AMD Radeon iGPU |
| Hardware-accelerated Transcoding |
✓ |
| Flash Memory |
4GB (Dual boot OS protection) |
| SSD Cache Acceleration Support |
✓ |
| Wake on LAN (WOL) |
✓ |
| Jumbo Frame |
✓ |
| USB 3.2 Gen 2 (10Gbps) Port |
2 x USB 3.2 (1x Type-C with DPI included , 1x Type-A) (10Gb/s) |
| HDMI™ Output |
1 x HDMI™ 1.4b ( up to 3840 x 2160 @ 30Hz ) |
| LED Indicators |
Power/Status, LAN, USB, SSD1-12 |
| Buttons |
Power, Reset, USB Auto Copy |
| Power Consumption: Disk Standby Mode |
69.01 |
| RJ-45 2.5GbE LAN Port |
2 (2.5G/1G/100M/10M) |
| SR-IOV |
✓ |
| Power Consumption: Operating Mode, Typical |
102.54 |
| Operating System |
QuTS hero h5.2.8 |
