| CPU Model |
Intel® Celeron® N5095 4-core/4-thread processor, burst up to 2.9 GHz |
| CPU Architecture |
64-bit x86 |
| Hardware Encryption Engine |
✓ (AES-NI) |
| Memory |
8 GB SODIMM DDR4 (1 x 8 GB) |
| Drive Bays |
8 x 3.5-inch SATA 6Gb/s, 3Gb/s |
| Compatible Drive Type |
3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA solid state drives |
| Hot Swappable Drive |
✓ (Not supported M.2 SSD) |
| Power Supply Unit / Adapter |
300W (x2), 100-240V |
| Total Memory Slots |
8 GB |
| Maximum Memory Capacity |
16 GB (2 x 8GB) |
| M.2 Drive Slots |
Optional via a PCIe adapter |
| PCIe Expansion |
1 Slot 1: PCIe Gen 3 x2 |
| Form Factor (RU) |
2U Short Depth Rackmount |
| RJ-45 10GbE LAN Port |
Optional via network adaptor |
| Graphic Processors |
Intel® UHD Graphics |
| Floating Point Unit |
✓ |
| Hardware-accelerated Transcoding |
✓ |
| Flash Memory |
4GB (Dual boot OS protection) |
| SSD Cache Acceleration Support |
✓ |
| Wake on LAN (WOL) |
✓ |
| Jumbo Frame |
✓ |
| USB 3.2 Gen 2 (10Gbps) Port |
2 x Type A USB 3.2 Gen 2 |
| HDMI™ Output |
1, HDMI™ 1.4b |
| LED Indicators |
HDD 1-8, Status, LAN, Expansion, Power |
| Buttons |
Power, Reset |
| Power Consumption: Disk Standby Mode |
31.742 |
| RJ-45 2.5GbE LAN Port |
2 (2.5G/1G/100M/10M) |
| Power Consumption: Operating Mode, Typical |
55.83 |
| USB 2.0 port |
2 |
| Operating System |
QTS 5.2.6 |
