| CPU Model |
Intel® Pentium® Gold G7400 2-core/4-thread 3.7 GHz Processor |
| CPU Architecture |
64-bit x86 |
| Hardware Encryption Engine |
✓ (AES-NI) |
| Memory |
8 GB SODIMM DDR4 (1 x 8 GB) |
| Drive Bays |
4 x 3.5-inch SATA 6Gb/s, 3Gb/s |
| Compatible Drive Type |
3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA solid state drives |
| Hot Swappable Drive |
✓ (Not supported M.2 SSD) |
| USB 3.2 Gen 1 Port |
1 |
| Power Supply Unit / Adapter |
250W, 100-240V |
| Total Memory Slots |
2 x SODIMM DDR4 |
| Maximum Memory Capacity |
64 GB ( 2 x 32 GB) |
| M.2 Drive Slots |
2 x M.2 2280 PCIe Gen 3 x2 slots |
| PCIe Expansion |
2 Slot 1: PCIe Gen 4 x16 Slot 2: PCIe Gen 3 x2 |
| Form Factor (RU) |
Tower |
| RJ-45 10GbE LAN Port |
Optional via PCIe expansion card |
| Graphic Processors |
Intel® UHD Graphics 710 |
| Floating Point Unit |
✓ |
| Hardware-accelerated Transcoding |
✓ |
| Flash Memory |
5GB (Dual boot OS protection) |
| SSD Cache Acceleration Support |
✓ |
| Wake on LAN (WOL) |
✓ |
| Jumbo Frame |
✓ |
| USB 3.2 Gen 2 (10Gbps) Port |
1 x Type-C USB 3.2 Gen 2 10Gbps 1 x Type-A USB 3.2 Gen 2 10Gbps |
| HDMI™ Output |
1, HDMI™ 1.4b (up to 4096 x 2160 @ 30Hz) |
| LED Indicators |
HDD 1-4, Status, LAN, USB port, M.2 port |
| Buttons |
Power, Reset, USB Copy |
| Power Consumption: Disk Standby Mode |
34.906 |
| RJ-45 2.5GbE LAN Port |
2 (2.5G/1G/100M/10M) |
| Power Consumption: Operating Mode, Typical |
78.574 |
| Operating System |
QTS 5.2.8 |
