| CPU Model |
Intel® Xeon® W-1250 6-core/12-thread processor, up to 4.7 GHz |
| CPU Architecture |
64-bit x86 |
| Hardware Encryption Engine |
✓ (AES-NI) |
| Memory |
16 GB ECC UDIMM DDR4 (2 x 8 GB) |
| Drive Bays |
8 x 3.5-inch SATA 6Gb/s, 3Gb/s + 4 x 2.5-inch SATA 6Gb/s, 3Gb/s |
| Compatible Drive Type |
3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA hard disk drives 2.5-inch SATA solid state drives 2.5-inch bays: 2.5-inch SATA solid state drives |
| Hot Swappable Drive |
✓ (Not supported M.2 SSD) |
| Power Supply Unit / Adapter |
550W PSU, 100~240V |
| Total Memory Slots |
4 x UDIMM DDR4 |
| Maximum Memory Capacity |
128 GB (4 x 32 GB) |
| M.2 Drive Slots |
2 x M.2 22110/2280 NVMe PCIe Gen3 x4 slots |
| PCIe Expansion |
3 Slot 1: PCIe Gen3 x8 Slot 2: PCIe Gen3 x4 Slot 3: PCIe Gen3 x4 |
| Form Factor (RU) |
Tower |
| RJ-45 10GbE LAN Port |
2 x 10GBASE-T (10G/1G) |
| Graphic Processors |
Intel® UHD Graphics P630 |
| Floating Point Unit |
✓ |
| Hardware-accelerated Transcoding |
✓ |
| Flash Memory |
5GB (Dual boot OS protection) |
| SSD Cache Acceleration Support |
✓ |
| Wake on LAN (WOL) |
✓ |
| Jumbo Frame |
✓ |
| USB 3.2 Gen 2 (10Gbps) Port |
2 x Type-C 3 x Type-A |
| HDMI™ Output |
1, HDMI™ 1.4b (up to 4096 x 2160 @ 30Hz) |
| LED Indicators |
System status, LAN, USB, Disk 1~12, M.2 SSD 1~2 |
| Buttons |
Power, Reset, USB Auto Copy |
| Power Consumption: Disk Standby Mode |
85.216 |
| RJ-45 2.5GbE LAN Port |
4 (2.5G/1G/100M/10M) |
| Power Consumption: Operating Mode, Typical |
97.492 |
| Operating System |
QTS 5.2.8 |
