| CPU Model |
AMD Ryzen™ 7 7000 series 8-core/16-thread processor, burst up to 5.3 GHz |
| CPU Architecture |
64-bit x86 |
| Hardware Encryption Engine |
✓ (AES-NI) |
| Memory |
32 GB UDIMM DDR5 (1x 32 GB) |
| Drive Bays |
12 x 3.5-inch SATA 6Gb/s, 3Gb/s |
| Compatible Drive Type |
3.5-inch SATA hard disk drives 2.5-inch SATA solid state drives |
| Hot Swappable Drive |
✓ (Not supported M.2 SSD) |
| Power Supply Unit / Adapter |
550W(x2), 100-240V |
| Total Memory Slots |
4 x UDIMM DDR5 Support optional ECC memory |
| Maximum Memory Capacity |
192 GB (4 x 48 GB) |
| M.2 Drive Slots |
2 x M.2 2280 PCIe Gen 5 x2 slots |
| PCIe Expansion |
3 Slot 1: Gen 4 x 4 Slot 2: Gen 4 x 8 or Gen 4 x 4* Slot 3: Gen 4 x 4 |
| Form Factor (RU) |
2U Rackmount |
| RJ-45 10GbE LAN Port |
2 x 10GBASE-T (10G/5G/2.5G/1G/100M) |
| Graphic Processors |
AMD Radeon™ Graphics |
| Floating Point Unit |
✓ |
| Hardware-accelerated Transcoding |
✓ |
| Flash Memory |
5GB (Dual boot OS protection) |
| SSD Cache Acceleration Support |
✓ |
| Wake on LAN (WOL) |
✓ |
| Jumbo Frame |
✓ |
| USB 3.2 Gen 2 (10Gbps) Port |
2 x Type-A USB 3.2 Gen 2 10Gbps |
| LED Indicators |
Power Status, HDD 1-12, M.2 SSD 1-2, Status, LAN, storage expansion port status |
| Buttons |
Power, Reset |
| Power Consumption: Disk Standby Mode |
82.247 |
| RJ-45 2.5GbE LAN Port |
2 (2.5G/1G/100M/10M) |
| Power Consumption: Operating Mode, Typical |
367.65 |
| Operating System |
QTS 5.2.8 |
