| CPU Model |
Intel® Xeon® D-2142IT 8-core 1.90 GHz processor, up to 3.0 GHz |
| CPU Architecture |
64-bit x86 |
| Hardware Encryption Engine |
✓ (AES-NI) |
| Memory |
64 GB RDIMM DDR4 ECC per controller |
| Drive Bays |
24 x 2.5-inch |
| Compatible Drive Type |
2.5-inch bays: 2.5-inch SAS/SATA hard disk drives 2.5-inch SAS/SATA solid state drives |
| Hot Swappable Drive |
✓ |
| RJ-45 1GbE LAN Port |
3 for each controller (assign one for remote management) |
| USB 3.2 Gen 1 Port |
2 per each controller |
| Power Supply Unit / Adapter |
Redundant/ Hot Swap Power Vin:90~264VAC;700W |
| Total Memory Slots |
16 x R-DIMM/LR-DIMM DDR4 8 x R-DIMM/LR-DIMM DDR4 per controller |
| Maximum Memory Capacity |
1024GB (16 x 64GB) 512 GB (8 x 64GB) per controller |
| PCIe Expansion |
2 per controller Slot 1: PCIe Gen 3 x8 (CPU) Slot 2: PCIe Gen 3 x8 (CPU) |
| Form Factor (RU) |
2U Rackmount |
| RJ-45 10GbE LAN Port |
4 x 10GbE SFP+ for each controller |
| Floating Point Unit |
✓ |
| Flash Memory |
4GB (Dual boot OS protection) |
| SSD Cache Acceleration Support |
✓ |
| Wake on LAN (WOL) |
✓ |
| Jumbo Frame |
✓ |
| LED Indicators |
System Power LED (Green): on/off System Status (Green/ Red): in operation, system errors, low power, degraded RAID mode, memory failure, fan/power supply failure, system/disk temperature too high, storage pool reaching threshold value, system performing |
| Buttons |
Power, Reset |
| Power Consumption: Operating Mode, Typical |
579.59 |
| Operating System |
QES 2.2.1 |
