| CPU Model |
Intel ® Atom® C5125 8-core processor, 2.8GHz |
| CPU Architecture |
64-bit x86 |
| Hardware Encryption Engine |
✓ (AES-NI) |
| Memory |
8 GB non-ECC UDIMM DDR4 (1 x 8 GB) |
| Drive Bays |
12 x 3.5-inch + 4 x 2.5-inch SATA 6Gb/s, 3Gb/s |
| Compatible Drive Type |
3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA solid state drives 2.5-inch bays: 2.5-inch SATA solid state drives |
| Hot Swappable Drive |
✓ |
| USB 3.2 Gen 1 Port |
4 |
| Power Supply Unit / Adapter |
550W, 100-240V |
| Total Memory Slots |
4 x U-DIMM DDR4 Support ECC memory |
| Maximum Memory Capacity |
128 GB (4 x 32 GB) |
| M.2 Drive Slots |
2 x M.2 2280 PCIe Gen 3 x2 slots |
| PCIe Expansion |
3 Slot 1: PCIe Gen 3 x4 Slot 2: PCIe Gen 3 x4 Slot 3: PCIe Gen 3 x4 |
| Form Factor (RU) |
Tower |
| RJ-45 10GbE LAN Port |
Optional via PCIe expansion card |
| Floating Point Unit |
✓ |
| Flash Memory |
5GB (Dual boot OS protection) |
| SSD Cache Acceleration Support |
✓ |
| Wake on LAN (WOL) |
✓ |
| Jumbo Frame |
✓ |
| LED Indicators |
Power/Status, LAN, USB, HDD1-12, SSD 1-4, M.2 SSD 1-2 |
| Buttons |
Power, Reset, USB Auto Copy |
| Power Consumption: Disk Standby Mode |
68.004 |
| RJ-45 2.5GbE LAN Port |
2 (2.5G/1G/100M/10M) |
| SR-IOV |
✓ |
| Power Consumption: Operating Mode, Typical |
104.65 |
| Operating System |
QuTS hero h5.6.0 |
