| CPU Model |
AMD Ryzen™ Embedded V1500B 4-core/8-thread 2.2 GHz processor |
| CPU Architecture |
64-bit x86 |
| Hardware Encryption Engine |
✓ (AES-NI) |
| Memory |
16 GB UDIMM DDR4 (1 x 16 GB) |
| Drive Bays |
16 x 3.5-inch SATA 6Gb/s, 3Gb/s |
| Compatible Drive Type |
3.5-inch SATA hard disk drives 2.5-inch SATA solid state drives |
| Hot Swappable Drive |
✓ (Not supported M.2 SSD) |
| USB 3.2 Gen 1 Port |
1 x Type-A |
| Power Supply Unit / Adapter |
550W (x2), 100-240V AC, 50-60Hz, 7-3.5A |
| Total Memory Slots |
2 x UDIMM DDR4 Support ECC memory |
| Maximum Memory Capacity |
64 GB (2 x 32 GB) |
| M.2 Drive Slots |
Optional via a QNAP QM2 PCIe card |
| PCIe Expansion |
2 x PCIe Gen3 x4 |
| Form Factor (RU) |
3U Rackmount |
| RJ-45 10GbE LAN Port |
Optional via a network adapter |
| Floating Point Unit |
✓ |
| Hardware-accelerated Transcoding |
Optional via a PCIe graphics card |
| Flash Memory |
5GB (Dual boot OS protection) |
| SSD Cache Acceleration Support |
✓ |
| Wake on LAN (WOL) |
✓ |
| Jumbo Frame |
✓ |
| USB 3.2 Gen 2 (10Gbps) Port |
2 x Type-C 1 x Type-A |
| HDMI™ Output |
Optional via a PCIe graphics card |
| LED Indicators |
HDD 1-16, Status, LAN, USB, Power |
| Buttons |
Power, Reset |
| Power Consumption: Disk Standby Mode |
47.75 |
| RJ-45 2.5GbE LAN Port |
2 (2.5G/1G/100M/10M) |
| Power Consumption: Operating Mode, Typical |
97.34 |
| Operating System |
QTS 5.2.6 |
